PART NO. |
THREAD E |
HOSE BORE |
DIMENSIONS |
||||
|
DN |
DASH |
A |
C |
H |
S2 |
||
|
20291-12-02 |
M12X1.25 |
4 |
02 |
26.5 |
8 |
30.5 |
17 |
|
20291-12-04 |
M12X1.25 |
6 |
04 |
30 |
8 |
33.5 |
17 |
|
20291-14-04 |
M14X1.5 |
6 |
04 |
30 |
8.5 |
34 |
19 |
|
20291-14-05 |
M14X1.5 |
8 |
05 |
33 |
8.5 |
37 |
19 |
|
20291-16-04 |
M16X1.5 |
6 |
04 |
30 |
8 |
35 |
22 |
|
20291-16-05 |
M16X1.5 |
8 |
05 |
34 |
8 |
38 |
22 |
|
20291-16-06 |
M16X1.5 |
10 |
06 |
35.3 |
8 |
40.3 |
22 |
|
20291-18-05T |
M18X1.5 |
8 |
05 |
33 |
8 |
39 |
24 |
|
20291-18-06 |
M18X1.5 |
10 |
06 |
35.75 |
8 |
41.3 |
24 |
|
20291-22-08 |
M22X1.5 |
12 |
08 |
41 |
10 |
48 |
27 |
|
20291-22-10 |
M22X1.5 |
16 |
10 |
57.5 |
10 |
53 |
27 |
|
20291-24-08T |
M24X1.5 |
12 |
08 |
41 |
11 |
45.5 |
30 |
|
20291-27-04T |
M27X1.5 |
6 |
04 |
30 |
10 |
35.5 |
32 |
|
20291-27-08T |
M27X1.5 |
12 |
08 |
41 |
10 |
46 |
32 |
|
20291-27-10T |
M27X1.5 |
16 |
10 |
56 |
10 |
51 |
32 |
|
20291-30-12 |
M30X1.5 |
20 |
12 |
66.2 |
11 |
63.5 |
36 |
|
20291-33-14 |
M33X2 |
22 |
14 |
71.2 |
13 |
65 |
41 |
|
20291-36-14T |
M36X2 |
22 |
14 |
71.2 |
13 |
61 |
41 |
|
20291-36-16 |
M36X2 |
25 |
16 |
76.7 |
13 |
70 |
41 |
|
20291-39-16T |
M39X2 |
25 |
16 |
76.7 |
13 |
67.5 |
46 |
|
20291-42-20 |
M42X2 |
32 |
20 |
91.5 |
15 |
82.5 |
50 |
|
20291-45-20T |
M45X2 |
32 |
20 |
91.5 |
15 |
78.5 |
55 |
|
20291-52-20T |
M52X2 |
32 |
20 |
91.5 |
17 |
78.5 |
60 |
|
20291-52-24T |
M52X2 |
40 |
24 |
109.4 |
17 |
92 |
60 |
|
20291-60-28T |
M60X2 |
45 |
28 |
119.9 |
20 |
106.5 |
70 |
|
20291-64-32T |
M64X2 |
50 |
32 |
130.95 |
23 |
113.3 |
75 |
|
Note: 1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 20292-xx-xx. |
|||||||
