PART NO. |
THREAD E |
HOSE BORE |
DIMENSIONS |
||||
|
DN |
DASH |
A |
C |
H |
S2 |
||
|
22191-02-04 |
G1/8"X28 |
6 |
04 |
30 |
2 |
38.5 |
14 |
|
22191-04-03 |
G1/4"X19 |
5 |
03 |
27 |
4 |
35 |
19 |
|
22191-04-04 |
G1/4"X19 |
6 |
04 |
30 |
4 |
38.5 |
19 |
|
22191-04-05 |
G1/4"X19 |
8 |
05 |
33 |
4 |
41.5 |
19 |
|
22191-06-05 |
G3/8"X19 |
8 |
05 |
33 |
5 |
42 |
22 |
|
22191-06-06 |
G3/8"X19 |
10 |
06 |
35.3 |
5 |
44.8 |
22 |
|
22191-06-08 |
G3/8"X19 |
12 |
08 |
41 |
5 |
50 |
22 |
|
22191-08-06T |
G1/2"X14 |
10 |
06 |
35.3 |
6 |
46.8 |
27 |
|
22191-08-08 |
G1/2”X14 |
12 |
08 |
41 |
6 |
52 |
27 |
|
22191-08-10 |
G1/2"X14 |
16 |
10 |
56.5 |
6 |
58 |
27 |
|
22191-10-10 |
G5/8"X14 |
16 |
10 |
56.5 |
8 |
57.5 |
30 |
|
22191-10-12 |
G5/8"X14 |
20 |
12 |
65.4 |
8 |
67 |
30 |
|
22191-12-08T |
G3/4"X14 |
12 |
08 |
41 |
9.5 |
52 |
32 |
|
22191-12-10 |
G3/4"X14 |
16 |
10 |
56.5 |
9.5 |
58.5 |
32 |
|
22191-12-12 |
G3/4"X14 |
20 |
12 |
65.5 |
9.5 |
68 |
32 |
|
22191-16-12T |
G1"X11 |
20 |
12 |
66.2 |
11 |
68.5 |
41 |
|
22191-16-14 |
G1"X11 |
22 |
14 |
71.2 |
11 |
69.5 |
41 |
|
22191-16-16 |
G1"X11 |
25 |
16 |
76.7 |
11 |
75 |
41 |
|
22191-20-16T |
G1.1/4"X11 |
25 |
16 |
76.7 |
10 |
78 |
50 |
|
22191-20-20W |
G1.1/4"X11 |
32 |
20 |
92.3 |
10 |
85.3 |
50 |
|
22191-24-24W |
G1.1/2"X11 |
40 |
24 |
109.4 |
11.5 |
108 |
55 |
|
22191-32-32W |
G2"X11 |
50 |
32 |
133.1 |
15 |
123.8 |
70 |
|
Note: 1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 22192-xx-xx. |
|||||||
