PART NO. |
THREAD |
TUBE O.D. |
O-RING |
DIMENSIONS |
|||||
|
E |
F |
F end |
A |
B |
S1 |
S2 |
S3 |
||
|
1QH9-14-120G |
M14X1.5 |
M12X1.25 |
8 |
009.3X2.4 |
30.2 |
32 |
14 |
17 |
17 |
|
1QH9-16-140G |
M16X1.5 |
M14X1.5 |
10 |
011.3X2.4 |
32 |
35.5 |
16 |
19 |
19 |
|
1QH9-18-160G |
M18X1.5 |
M16X1.5 |
12 |
013.3X2.4 |
34 |
36 |
19 |
22 |
22 |
|
1QH9-22-180G |
M22X1.5 |
M18X1.5 |
14 |
015.3X2.4 |
37.5 |
39.5 |
22 |
24 |
27 |
|
1QH9-27-220G |
M27X1.5 |
M22X1.5 |
18 |
019.3X2.4 |
41.5 |
43.5 |
27 |
27 |
32 |
|
1QH9-30-27OG |
M30X1.5 |
M27X2 |
20 |
023.5X3.0 |
45.8 |
50 |
30 |
32 |
36 |
|
1QH9-33-270G |
M33X2 |
M27X2 |
22 |
023.5X3.0 |
49.5 |
52 |
33 |
32 |
41 |
|
1QH9-36-330G |
M36X2 |
M33X2 |
25 |
029.5X3.0 |
51.5 |
54 |
36 |
41 |
41 |
|
1QH9-39-330G |
M39X2 |
M33X2 |
28 |
029.5X3.0 |
55.5 |
57.2 |
41 |
41 |
46 |
|
1QH9-45-420G |
M45X2 |
M42X2 |
34 |
038.5X3.0 |
62.5 |
61 |
48 |
50 |
50 |
|
Note:1 In case if you are interested to order the adapter in complete set with sleeve and nut,it is necessary to insert suffix “RN” after our part NO.,for example 1QH9-22- 18/RN，The sleeve NO.is NB500-Q and the nut No. is NB200-Q. 2 F end is connected with ISO 9974-1 port and connected with ISO 6149-1 port without retaining ring. |
|||||||||
