PART NO. |
THREAD |
TUBE O.D. |
DIMENSIONS |
MPa |
||||||
|
E |
F |
D1 |
A |
L1 |
S1 |
S2 |
|
|
||
|
2GC-02-12 |
G1/8"X28 |
M12X1.5 |
6 |
9.5 |
20.5 |
14 |
14 |
|
|
31.5 Light series L |
|
2GC-04-14 |
G1/4”X19 |
M14X1.5 |
8 |
10 |
23.5 |
19 |
17 |
|
|
|
|
2GC-04-16 |
G1/4”X19 |
M16X1.5 |
10 |
10 |
24 |
19 |
19 |
|
|
|
|
2GC-06-18 |
G3/8"X19 |
M18X1.5 |
12 |
11.5 |
25.5 |
22 |
22 |
|
|
|
|
2GC-08-22 |
G1/2"X14 |
M22X1.5 |
15 |
14 |
28.5 |
27 |
27 |
|
|
|
|
2GC-08-26 |
G1/2"X14 |
M26X1.5 |
18 |
14 |
29 |
27 |
32 |
|
|
|
|
2GC-12-30 |
G3/4"X14 |
M30X2 |
22 |
15.5 |
32 |
32 |
36 |
|
|
16 Light series L |
|
2GC-16-36 |
G1"X11 |
M36X2 |
28 |
18 |
35 |
41 |
41 |
|
|
|
|
2GC-20-45 |
G1.1/4"X11 |
M45X2 |
35 |
20 |
38 |
50 |
50 |
|
|
|
|
2GC-24-52 |
G1.1/2"X11 |
M52X2 |
42 |
21.5 |
41.5 |
55 |
60 |
|
|
|
|
2GD-04-14 |
G1/4"X19 |
M14X1.5 |
6 |
10 |
23 |
19 |
17 |
|
|
63 Heavy series S |
|
2GD-04-16 |
G1/4"X19 |
M16X1.5 |
8 |
10 |
26 |
19 |
19 |
|
|
|
|
2GD-06-18 |
G3/8"X19 |
M18X1.5 |
10 |
11.5 |
25 |
22 |
22 |
|
|
|
|
2GD-06-20 |
G3/8"X19 |
M20X1.5 |
12 |
11.5 |
28.5 |
22 |
24 |
|
|
|
|
2GD-08-22 |
G1/2"X14 |
M22X1.5 |
14 |
14 |
31.5 |
27 |
27 |
|
|
|
|
2GD-08-24 |
G1/2"X14 |
M24X1.5 |
16 |
14 |
30 |
27 |
30 |
|
|
40 Heavy series S |
|
2GD-12-30 |
G3/4"X14 |
M30X2 |
20 |
15.5 |
36 |
32 |
36 |
|
|
|
|
2GD-16-36 |
G1"X11 |
M36X2 |
25 |
18 |
38.5 |
41 |
46 |
|
|
|
|
2GD-20-42 |
G1.1/4”X11 |
M42X2 |
30 |
20 |
42 |
50 |
50 |
|
|
|
|
2GD-24-52 |
G1.1/2"X11 |
M52X2 |
38 |
21.5 |
47.5 |
55 |
60 |
|
|
31.5Heavy seriesS |
